I believe they are a stick on job

_________________
1994 Suzuki Swift GA SOHC. 4/5
Vogtland lowering coils
Ngk plugs
8mm silicon wires.

They have a few mounting studs.

_________________
1995 Swift w/16V 4.39s, 3tech cam, Esteem t-body, Header, needs more.
1995 Gt Mustang "Boss Shinoda" package.
1999 F150 4x4 Supercharged
1967 Mustang 428 auto, never ending expensive project
1993 Civic si h22a, fell in my lap, couldn't resist!

I would think that you could line it up around the wiper hole and set it level and that would be pretty close.

Ken.......

Trouble is a mid wing car uses a different washer set up.

_________________
.

'94 Metro LSi 'Green Machine'
'94 RHD (Totaled)
Vail, AZ


.

I don't think this will help much, but I traced out a template when I installed my midwing a couple years ago.

In the end, I think I made some short studs, sharpened one end, and threaded them into the midwing. Then I lined it up on the car, and pressed on the mounting areas to leave marks in the paint where the holes go.

_________________
1994 Geo Metro Turbo

_________________
.

'94 Metro LSi 'Green Machine'
'94 RHD (Totaled)
Vail, AZ


.

Gary, I know you also posted this question on GMF. To save time, I will respond here on TS, and add a link to your GMF post.

The information for the mid wing location was measured from my stock Canadian market 1991 Chevrolet Sprint Turbo hatch.

General: The mid wing spoiler is secured to the hatch with a total of 4 Phillips pan head bolts. (2 per side).

This photo shows the location of one of the 2 upper pan head bolts. The hatch sheet metal is double walled here, so an access hole of 3/4"diameter is needed to allow access for the upper mid wing bolts to pass through the exterior sheet metal to the mid wing spoiler. The round factory black plastic tape cover has been peeled back in this photo to show the upper bolt and access hole.



The 2 lower bolts go directly through the sheet metal to the mid wing, and use a fender washer.


Below is a picture view of the upper and lower bolts attached to the mid wing. The upper bolt is covered by a round black factory tape over the 3/4 inch access hole.


Next below, is a picture of the hatch of a Swift without the mid wing. This example has a GT upper hatch spoiler. Note there are no holes pre-drilled for an owner to simply bolt on a mid wing spoiler later on - for cars without a mid wing spoiler from the factory.

I have added several reference points to the hatch (marked in red) to allow one to locate where to drill the upper and lower mounting bolt holes on each side of the hatch door, to be drilled from the inside of the hatch door outward through the external sheet metal. You can use a smaller drill bit first so you can check that the mid wing holes line up properly before drilling full size holes.

You may need to zoom in on the photo to see the red letter reference symbols better:

X= bottom edge of hatch door sheet metal (at end of an imaginary line passing through centres of L, X, Y)
Y= upper edge of holes in sheet metal where the black adjustable rubber hatch bumpers are screwed in.
Z= centre point of the black plastic plugs located under the upper hatch door hinges.
U= location of the centre point of the upper mid wing bolts.
L= location of the centre point of the lower mid wing bolts.

Distances and measurements:
X to L = 7.25 inches
U to Z = 16.75 inches (centre to centre)
U TO L = 6.50 inches (bolt centres)
L TO Y = 4.00 inches (bolt centre to edge of hole)
U to edge of black hatch trim adjacent to hatch window = 1.50 inches (bolt centre to edge)
L to edge of black hatch trim adjacent to hatch window = 1.50 inches (bolt centre to edge)

To be clear the 1.5 inch distance is the distance between either of the mid wing bolt centres (marked U or L) and the *edge* of the exposed black trim on the side of the hatch door, as seen on the right side of the updated photo and represented as thin red lines .

You're welcome!

I also found an old GMF thread written by razr769 about mid wing installation. For some reason, the only way a search for this post finds the thread is via Google, or if you use the GMF search engine, you had to know that Member razr769 posted a thread 3 years ago about mid wings.

His pictures show more detail about retrofitting the mid wing to a Metro. One of the steps he showed involve [denting] the hatch where the mounting pads on the underside of the mid wing make contact with the hatch exterior sheet metal. I don't fully understand why this was necessary, as the mid wing's mounting pads are in perfect contact with a hatch door's sheet metal surface, without need for metal modification.

Picture of exterior holes on razr769's hatch door.


Link to his thread:
Modifying My Midwing (posted by Razr769 on Jan 6 2013)http://geometroforum.com/topic/5040173/1/
